Barrier Blocks
Series 141
.438 Density, 6-32 x 1/4"
BH Screw, Open Bottom,
Double Row
Electrical Characteristics
Voltage Rating: 250 VAC RMS maximum
Current Rating: 20 Amps maximum
Maximum Watts Per Terminal: 5000
Mechanical Characteristics
Maximum Wire Size: #14 AWG
Recommended Tightening Torque: 12 lb.-in.
Dimensions
Ordering Information
No. of
Terminals
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Standard Screw
Catalog No.
1-141
2-141
3-141
4-141
5-141
6-141
7-141
8-141
9-141
10-141
11-141
12-141
13-141
14-141
15-141
16-141
17-141
18-141
19-141
20-141
“M”
Dim.
.875
1.312
1.750
2.187
2.625
3.062
3.500
3.938
4.375
4.813
5.250
5.687
6.125
6.562
7.000
7.437
7.875
8.312
8.750
9.187
“L”
Dim.
1.187
1.625
2.062
2.500
2.938
3.375
3.812
4.250
4.687
5.125
5.562
6.000
6.437
6.875
7.312
7.750
8.187
8.625
9.062
9.500
Marketed exclusively through distribution.
Call Toll Free: 1 (800) 323-9612
2-8
